I've had to replace all of my sleeves and washers on my G3 machines. I didn't need studs so I didn't try to order any, I'll look for a number.

Sorry, I can't find them in my book.

Yeah I had no success with any of my TK parts manuals. In the morning I will call them directly and see if they have some. When I arrived the car had a blown amptrap. I changed it and went to run the car on inspection and I had my own personal fourth of july firework show. It ate that stud about 1/2 way thru.

My G3's are bad about grease coming out of the bearing carrier on the inside plate and getting up on the rigging and armature. I had to take and remove the sleeves, washers and brush holder arms and wash all of them and put them back. I chose that method over trying to wash all of them inside the machine. It was very time consuming and hard considering I mostly had to use one hand while laying on the floor for the bottom ones. Those grease overflow spring loaded pressure things don't work in my opinion. I eventually removed those grease overflow pop offs and put a little threaded nipple with some plastic tubing to let the grease go away from the motor. I'll try and post pics.

When I pulled those sleeves and washers out they were all oily and full of carbon.... They were burning like charcoal inside the arms conducting to ground.

Before:

800w" sizes="(max-width: 760px) 100vw, 760px" /> 800w" sizes="(max-width: 760px) 100vw, 760px" width="800" height="450" alt="" decoding="async" loading="eager" fetchpriority="high" />

After:

800w" sizes="(max-width: 760px) 100vw, 760px" /> 800w" sizes="(max-width: 760px) 100vw, 760px" width="800" height="450" alt="" decoding="async" loading="lazy" />

This stud holds two holders. The stud and surface looked clean besides a lot of carbon. I didn't get to blow out the rigging this quarter so it's my fault lack of maintenance.

I would hit up a motor shop
I would think those studs would be common sizes especially on some hoist motors
IE GD 105 etc etc
You will vary rarely see someone change a G3 or other big gearless machines out just to costly, the GD 105 motors that's a different story.

If you could find a older GD 105 etc manual the part number would be listed

Finally got a call back from TK parts and spoke to someone who isn't dumbfounded when I explain what I needed I got them. Thanks for the help. Looks like Monday I'll be breaking out the dust masks and the tivek suits and clearing some carbon.
